INPUT

Dual input

Optional

Standard

Phase

3 Phase + Neutral + Ground, 380V/400V/415V(line-line)

Input voltage range

304~478Vac (line-line),full load; 228V~304Vac (line-line),load decreases linearly according to the min phase voltage

Rate frequency

50/60Hz

Input frequency range

40Hz～70Hz

Input power factor

> 3% (100% Linear load)

BYPASS

Rate voltage

380V/400V/415VAC (line-line)

Rate frequency

50/60Hz

Input voltage range

Settable,  -40%～+25%

Bypass frequency range

Settable, ±1Hz, ±3Hz, ±5Hz

Bypass overload

110% long term operation; 125% for 5 mins ;150% for 1 min; >150% for 1s

OUTPUT

Rate voltage

380/400/415VAC  (line-line)

Voltage regulation

±1(0~100% linear load)

Rate frequency

50/60Hz

Frequency precision

0.1%

Output power factor

1

Output THDu

<1% , Linear load; <6%, Non-linear load

Crest factor

3:1

Inverter overload

110% for 1 hour; 125% for 10 mins ;150% for 1 min; >150% for 200 ms

BATTERY

Voltage

±240VDC

Battery number

40pcs (Settable: even number from 32 to 44)

Voltage precision

±1%

Charge power

up to 20% * Output active power Standard

Battery cold start

Standard

SYSTEM

Efficiency

AC mode

96.0%

ECO mode

98.0%

DC mode

96.0%

Display

7.0" color touch screen LCD + LED + keyboard

IP class

IP20

Interface

RS232, RS485, Programmable Dry Contact

Option

PDU for RM150/25C,SNMP Card, Parallel kit,SPD, LBS

Temperature

Operation: 0～ 40 ℃  Storge: -40 ～70 ℃ 0 ～

Relative humidity

0 ～95% Non-condensing

Altitude

<1000m. Within 1000m to 2000m, power derate 1% for every 100m rise

Noise (1 Meter)

65dB @ 100% load, 62dB @ 45% load

Applicable standards

Safety: IEC/EN 62040-1-1 EMC: IEC/EN 62040-2 Performance: IEC/EN 62040-3

PHYSICAL

Weight (kg)

Cabinet

140

160

Power module

18

Dimensin WxDxH (mm)

Cabinet

482x916x931

482x916x1550

Power module

436x677x85
